Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 21,100 lb |
|---|---|
| Tire Size | front 18.4-34/14 rear 14.9-24/10 |
| Static Tipping Weight | 9,300 lb |
| Turning Radius | 217 in |
Engine
| Engine Model | D 50A |
|---|---|
| Power Measured @ | 2,400 rpm |
| Gross Power | 110.0 hp |
| Number of Cylinders | 6 |
| Aspiration | direct |
| Torque Measured @ | 1,500 rpm |
Hydraulic System
| Pump Flow Capacity | 58.2 gal/min |
|---|---|
| Relief Valve Setting | 1,350 psi |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 107 in |
| Wheelbase | 96 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 227 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 16.5 mph |
|---|---|
| Max Speed - Reverse | 16.5 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.30 yd³ |
|---|---|
| Bucket Capacity - struck | 1.80 yd³ |
| Dump Clearance at Max Raise | 122 in |
