Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 22,487 lb |
|---|---|
| Fuel Capacity | 51.6 gal |
| Tire Size | 20.5-25/12 |
| Static Tipping Weight | 14,992 lb |
| Operating Voltage | 24 V |
| Turning Radius | 193 in |
Engine
| Engine Model | D 50 B |
|---|---|
| Displacement | 313 in³ |
| Power Measured @ | 1,600 rpm |
| Gross Power | 120.0 hp |
| Number of Cylinders | 6 |
| Aspiration | direct injection |
| Torque Measured @ | 1,600 rpm |
Hydraulic System
| Pump Flow Capacity | 58.2 gal/min |
|---|---|
| Relief Valve Setting | 1,700 psi |
| Pump Type | Hamworthy |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 107 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 257 in |
| Hinge Pin - Max Height | 151 in |
Transmission
| Max Speed - Forward | 18.7 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Transmission Type | full power-shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 6.61 yd³ |
|---|---|
| Bucket Capacity - struck | 2.30 yd³ |
| Dump Clearance at Max Raise | 117 in |
| Bucket Width | 100 in |
