Volvo

EC160CL

Excavator

Operating Weight
37,038 lb
Max Digging Depth
227 in
Max Digging Depth
239 in
Net Power
116.7 hp
All excavators
Volvo EC160CL Excavator
1 / 5
Image 1 of 5
Image: tractorhouse.com

Specifications

52 data points

Operating Specifications

Operating Specifications specifications
Operating Weight37,038 lb
Fuel Capacity66.1 gal
Hydraulic Pump Flow Capacity76.7 gal/min
Hydraulic System Fluid Capacity70.1 gal
Engine Oil Capacity6.7 gal
Cooling System Fluid Capacity6.4 gal
Operating Voltage24 V
Swing Drive Fluid Capacity0.7 gal
Alternator Supplied Amperage80 A

Engine

Engine specifications
Engine ModelD6E EBE3
Displacement348 in³
Power Measured @1,800 rpm
Gross Power131.5 hp
Net Power116.7 hp
Torque Measured @1,350 rpm
Max Torque461 lb-ft
Engine MakeVolvo
Bore4 in
Stroke5 in

Dimensions

Dimensions specifications
Ground Clearance19 in
Height - Top of Cab115 in
Length of Track on Ground157 in
Tail Swing Radius101 in
Width to Outside of Tracks107 in
Removal Counterweight Clearance41 in

Undercarriage

Undercarriage specifications
Ground Pressure7 psi
Track Gauge88 in
Max Travel Speed3.5 mph
Shoe Size20 in
Drawbar Pull32,597 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth227 in
Max Reach Along Ground335 in
Max Loading Height241 in
Max Vertical Wall Digging Depth161 in
Max Cutting Height336 in
Shipping Length of Unit350 in
Shipping Height of Unit118 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed12 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth239 in
Max Vertical Wall Digging Depth179 in
Max Cutting Height347 in
Max Loading Height251 in
Max Reach Along Ground348 in
Shipping Length of Unit346 in
Shipping Height of Unit115 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth254 in
Max Cutting Height355 in
Max Loading Height258 in
Max Vertical Wall Digging Depth196 in
Max Reach Along Ground362 in
Shipping Length of Unit348 in
Shipping Height of Unit120 in
