Volvo
Caterpillar
120G
Motor Grader
17 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Tire Size | 14.00 x 24 G-2 |
|---|---|
| Fuel Capacity | 100.0 gal |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Tandem Case Fluid Capacity (each) | 26.5 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 12.5 gal |
| Alternator Supplied Amperage | 75 A |
| Transmission Fluid Capacity | 10.1 gal |
| Rear Diff/Final Drive Fluid Capacity | 6.1 gal |
Engine
| Engine Model | 6C8.3 |
|---|---|
| Displacement | 505 in³ |
| Aspiration | Turbocharged |
| Max Power | 180.0 hp |
| Net Power Gear 1-2 | 180.0 hp |
Dimensions
| Wheelbase | 240 in |
|---|---|
| Overall Length | 335 in |
| Width Over Tires | 101 in |
| Height to Top of Isomount Cab | 122 in |
| Blade Base | 103 in |
Transmission
| Max Speed - Forward | 28.5 mph |
|---|---|
| Max Speed - Reverse | 20.4 mph |
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 4 |
| Transmission Type | Powershift |
Front Axle
| Wheel Lean | 15 ° |
|---|---|
| Oscillation - Total | 16 ° |
Steering System
| Articulation Angle | 22 ° |
|---|
