Volvo
Manitou
ML40
Wheel Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 10,494 lb |
|---|---|
| Fuel Capacity | 22.8 gal |
| Tire Size | 12.5-20 |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Static Tipping Weight | 8,047 lb |
| Operating Voltage | 12 V |
| Turning Radius | 168 in |
| Engine Oil Fluid Capacity | 2.8 gal |
| Rear Axle Oscillation | 20 ° |
| Alternator Supplied Amperage | 80 A |
| Front Axle/Diff Fluid Capacity | 3.0 gal |
| Rear Axle/Diff Fluid Capacity | 3.2 gal |
Engine
| Engine Model | BF4L 1011FT |
|---|---|
| Displacement | 167 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 61.0 hp |
| Net Power | 58.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,800 rpm |
Hydraulic System
| Pump Flow Capacity | 13.8 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.1 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 107 in |
| Wheelbase | 85 in |
| Width Over Tires | 70 in |
| Reach at Max Lift and Dump | 31 in |
| Length with Bucket on Ground | 209 in |
| Hinge Pin - Max Height | 127 in |
Transmission
| Max Speed - Forward | 18.7 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 97 in |
| Breakout Force | 9,734 lb |
| Bucket Width | 72 in |
General Specifications
| Operating Weight lbs (kg) | 12,646 (5,736) — Starting 2025 Model Year |
|---|---|
| Bucket Capacity cu. yd. (cu m) | 1.3-2 (1-1.5) — Starting 2026 Model Year |
| Engine type | Volvo D3.3H — Starting 2025 Model Year |
| Max Dump Height ft.( m) | 8.5 (2.6) — Starting 2025 Model Year |
| OperatingWeight lbs. (kg) | 12,646-13,087 (5,736-5,936) — Starting 2026 Model Year |
| Engine Power Net hp (kW) | 74 (55) — Starting 2025 Model Year |
