Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Fuel Capacity | 39.7 gal |
|---|---|
| Hydraulic System Fluid Capacity | 25.1 gal |
| Engine Oil Fluid Capacity | 3.7 gal |
| Cooling System Fluid Capacity | 5.3 gal |
| Transmission Fluid Capacity | 0.4 gal |
| Rated Bucket Capacity | 1.80 – 2.60 yd³ |
| DEF tank capacity | 5.3 gal |
Engine
| Engine Model | Volvo D4J |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 100.0 hp |
| Net Power | 97.9 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,450 rpm |
| Make | Volvo |
Weights
| Operating Weight | 19,334 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 34.9 gal/min |
|---|---|
| Working pressure | 26 MPa 3771 psi |
| Engine speed | 2,200 rpm |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 117 in |
| Wheelbase | 104 in |
| Width Over Tires | 85 in |
| Length with Bucket on Ground | 251 in |
| Hinge Pin - Max Height | 145 in |
Bucket
| Dump Clearance at Max Raise | 111 in |
|---|---|
| Breakout Force | 15,961 lb |
General Specifications
| Operating Weight | 19,378 (8,790) — Starting 2024 Model Year |
|---|---|
| Bucket Capacity | 2.0 (1.5) — Starting 2024 Model Year |
| Engine type | Volvo D4J — Starting 2019 Model Year |
| Engine Power | 100 (75) — Starting 2024 Model Year |
| Max Dump Height | 9 (2.8) — Starting 2024 Model Year |
Drive System
| Transport speed, maximum | 18.7 mph |
|---|
Hydraulic cycle times (unloaded)
| Lift | 4.8 s |
|---|---|
| Lower | 3.2 s |
| Dump time | 1.5 s |
Steering System
| Articulation Angle | 40 ° |
|---|---|
| Maximum flow | 18.5 gal/min |
| Steering cylinders | 2 |
| Working pressure | 17.5 MPa 2538 psi |
Electrical System
| Voltage | 24 V |
|---|---|
| Battery capacity | — |
| Alternator rating | 3080/110 (W/A) |
| Starter motor output | 7.4 hp |
| Cold cranking capacity | 830 A |
Axles
| Axle oil front | 4.7 gal |
|---|---|
| Axle oil rear | 4.7 gal |
| Rear axle oscillation | 12 ° |
