Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 20,745 lb |
|---|---|
| Fuel Capacity | 39.7 gal |
| Hydraulic System Fluid Capacity | 25.1 gal |
| Static Tipping Weight | 14,462 lb |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 3.7 gal |
| Alternator Supplied Amperage | 110 A |
| Front Axle/Diff Fluid Capacity | 4.5 gal |
| Rear Axle/Diff Fluid Capacity | 4.9 gal |
| Cooling System Fluid Capacity | 5.3 gal |
| Transmission Fluid Capacity | 0.6 gal |
| Rated Bucket Capacity | 1.80 – 3.00 yd³ |
Engine
| Engine Model | D4H |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 117.0 hp |
| Net Power | 114.0 hp |
| Torque Measured @ | 1,450 rpm |
| Make | Volvo |
Weights
| Operating Weight | 20,790 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 34.9 gal/min |
|---|---|
| Raise Time | 6.4 s |
| Lower Time | 3.9 s |
| Dump Time | 1.6 s |
| Pump Type | Axial Piston Pump |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 104 in |
| Width Over Tires | 86 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 254 in |
| Hinge Pin - Max Height | 150 in |
Transmission
| Max Speed - Forward | 25.0 mph |
|---|---|
| Max Speed - Reverse | 25.0 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Dump Clearance at Max Raise | 113 in |
|---|---|
| Breakout Force | 16,186 lb |
| Bucket Width | 89 in |
General Specifications
| Operating Weight | 20,790 (9,410) — Starting 2016 Model Year |
|---|---|
| Bucket Capacity | 1.8 - 3.0 (1.4 - 2.3) — Starting 2016 Model Year |
| Engine type | Volvo D4H — Starting 2016 Model Year |
| Engine Power | 114 (85) — Starting 2016 Model Year |
| Max Dump Height | 9.4 (2.9) — Starting 2016 Model Year |
