Volvo
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 30,732 lb |
|---|---|
| Tire Size | 20.5 |
| Operating Voltage | 24 V |
| Rated Bucket Capacity | 2.60 – 8.70 yd³ |
Engine
| Engine Model | D6H TIER 4H |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 1,700 rpm |
| Gross Power | 171.0 hp |
| Net Power | 171.0 hp |
| Number of Cylinders | 6 |
| Aspiration | TURBOCHARGED |
| Torque Measured @ | 1,400 rpm |
| Make | Volvo |
Weights
| Operating Weight | 29,910 lb |
|---|
Hydraulic System
| Raise Time | 5.1 s |
|---|---|
| Lower Time | 2.7 s |
| Dump Time | 1.2 s |
Transmission
| Max Speed - Forward | 28.6 mph |
|---|---|
| Max Speed - Reverse | 28.6 mph |
| Transmission Type | HTE 125 |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Dump Clearance at Max Raise | 110 in |
|---|
