Volvo
L90E
- Operating Weight
- 33,290 lb
- Bucket Capacity - heaped
- 3.20 yd³
- Gross Power
- 166.0 hp
- Net Power
- 165.0 hp
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 33,290 lb |
|---|---|
| Fuel Capacity | 54.2 gal |
| Tire Size | 20.5R25 L2 |
| Hydraulic System Fluid Capacity | 30.4 gal |
| Static Tipping Weight | 25,265 lb |
| Operating Voltage | 24 V |
| Turning Radius | 235 in |
| Engine Oil Fluid Capacity | 5.3 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 55 A |
| Front Axle/Diff Fluid Capacity | 8.0 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 9.6 gal |
| Transmission Fluid Capacity | 10.6 gal |
Engine
| Engine Model | D6D LA E2 |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 166.0 hp |
| Net Power | 165.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 46.3 gal/min |
|---|---|
| Raise Time | 5.4 s |
| Lower Time | 2.5 s |
| Dump Time | 2.1 s |
| Relief Valve Setting | 3,771 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 119 in |
| Width Over Tires | 98 in |
| Reach at Max Lift and Dump | 49 in |
| Length with Bucket on Ground | 298 in |
| Hinge Pin - Max Height | 156 in |
Transmission
| Max Speed - Forward | 23.1 mph |
|---|---|
| Max Speed - Reverse | 23.1 mph |
| Transmission Type | Volvo HTE202 |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 28,169 lb |
| Bucket Width | 104 in |
