Wacker Neuson
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 9,826 lb |
|---|---|
| Max Speed - high range | 7.5 mph |
| Max Speed - low range | 4.3 mph |
| Fuel Capacity | 24.7 gal |
Engine
| Engine Model | Perkins 854 |
|---|---|
| Gross Power | 74.3 hp |
| Aspiration | Turbo Charged |
| Emission Tier Level | 4 |
Hydraulic System
| Pump Flow | 22.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,336 psi |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 64 in |
| Width Over Tracks | 18 in |
| Overall Height | 83 in |
| Length with Bucket | 145 in |
| Dump Height | 95 in |
| Length - without Bucket | 117 in |
| Dump angle | 45 ° |
| Angle of departure | 30 ° |
| Length - Track on Ground | 64 in |
| Hinge pin height - fully raised | 126 in |
| Dump reach | 22 in |
General Specifications
| Operating Width IN. (CM) | 78 (198) — Starting 2021 Model Year |
|---|---|
| Engine Power HP (KW) | 74 (55) — Starting 2021 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 2,450 (1,114) — Starting 2021 Model Year |
Loader
| Tipping Angle | 45 ° |
|---|---|
| Bucket Width | 78 in |
| Bucket Breakout Force | 6,722 lb |
| Boom breakout force | 6,160 lb |
| Rollback - Ground Level | 31 ° |
