XCG

140-8

Excavator

Operating Weight
30,424 lb
Max Digging Depth
220 in
Net Power
93.4 hp
All excavators
XCG 140-8 Excavator
1 / 5
Image 1 of 5
Image: casece.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight30,424 lb
Hydraulic Pump Flow Capacity63.5 gal/min
Hydraulic System Relief Valve Pressure4,641 psi

Engine

Engine specifications
Engine ModelBB-4BG1T
Displacement264 in³
Power Measured @2,200 rpm
Net Power93.4 hp

Dimensions

Dimensions specifications
Ground Clearance18 in
Length of Track on Ground119 in
Tail Swing Radius84 in
Width to Outside of Tracks103 in

Undercarriage

Undercarriage specifications
Max Travel Speed3.5 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth220 in
Max Reach Along Ground320 in
Max Loading Height239 in
Max Vertical Wall Digging Depth199 in
Shipping Length of Unit300 in
Shipping Height of Unit113 in

Bucket

Bucket specifications
Reference Bucket Capacity0.80 yd³
