Yanmar
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 8,605 lb |
|---|---|
| Max Speed - high range | 7.6 mph |
| Max Speed - low range | 5.1 mph |
| Fuel Capacity | 24.4 gal |
| Hydraulic System Fluid Capacity | 11.0 gal |
| Cooling System Fluid Capacity | 3.6 gal |
Engine
| Engine Model | 4TNV98C-NMSL |
|---|---|
| Displacement | 203 in³ |
| Net Power | 68.4 hp |
| Number of Cylinders | 4 |
| Engine Make | Yanmar |
| Engine Type | 4-Stroke Naturally Aspirated |
| Alternator | 95 A |
| Peak Torque | 179 lb-ft |
Hydraulic System
| Auxiliary hydraulic flow | 18.5 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Reach at Max Lift and Dump | 35 in |
| Length with Bucket | 145 in |
| Dump Height | 98 in |
| Length - without Bucket | 111 in |
| Track Gauge | 53 in |
| Dump angle | 40 ° |
| Hinge pin height - fully raised | 128 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|
Loader
| Tipping Angle | 5,000 ° |
|---|---|
| Breakout Force | — |
| Bucket Width | 66 in |
