Yanmar
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 3,836 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 15.4 gal/min |
| Hydraulic System Relief Valve Pressure | 2,988 psi |
Engine
| Engine Model | 3TNV70-XBV |
|---|---|
| Power Measured @ | 2,200 rpm |
| Net Power | 13.6 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Length of Track on Ground | 61 in |
| Tail Swing Radius | 25 in |
| Width to Outside of Tracks | 50 in |
Undercarriage
| Max Travel Speed | 2.7 mph |
|---|---|
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 88 in |
|---|---|
| Max Reach Along Ground | 91 in |
| Max Loading Height | 104 in |
| Shipping Length of Unit | 137 in |
| Shipping Height of Unit | 91 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
