Yanmar

VIO45-5B

Mini Excavator

Operating Weight
10,560 lb
Max Digging Depth
145 in
Net Power
39.5 hp
All mini excavators
Yanmar VIO45-5B Mini Excavator
1 / 5
Image 1 of 5
Image: ebay.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight10,560 lb
Fuel Capacity17.0 gal
Hydraulic Pump Flow Capacity19.8 gal/min
Hydraulic System Relief Valve Pressure3,133 psi

Engine

Engine specifications
Engine Model4TNV88
Power Measured @2,400 rpm
Net Power39.5 hp

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab103 in
Tail Swing Radius39 in
Width to Outside of Tracks77 in

Undercarriage

Undercarriage specifications
Ground Pressure4 psi
Max Travel Speed2.8 mph
Shoe Size14 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth145 in
Max Reach Along Ground229 in
Max Vertical Wall Digging Depth107 in
Max Loading Height155 in
Shipping Length of Unit207 in
Max Cutting Height235 in
Shipping Height of Unit103 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
