Yanmar

VIO75-A

Mini Excavator

Operating Weight
17,640 lb
Max Digging Depth
175 in
Net Power
58.2 hp
All mini excavators
Yanmar VIO75-A Mini Excavator
1 / 5
Image 1 of 5
Image: purplewave.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight17,640 lb
Fuel Capacity26.4 gal
Hydraulic Pump Flow Capacity54.0 gal/min
Hydraulic System Relief Valve Pressure3,553 psi

Engine

Engine specifications
Engine Model4TNV98-XBV
Power Measured @2,000 rpm
Net Power58.2 hp

Dimensions

Dimensions specifications
Ground Clearance16 in
Height - Top of Cab108 in
Tail Swing Radius46 in
Width to Outside of Tracks90 in

Undercarriage

Undercarriage specifications
Ground Pressure5 psi
Max Travel Speed2.9 mph
Shoe Size18 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth175 in
Max Reach Along Ground276 in
Max Vertical Wall Digging Depth158 in
Max Loading Height185 in
Shipping Length of Unit248 in
Max Cutting Height288 in
Shipping Height of Unit108 in

Bucket

Bucket specifications
Reference Bucket Capacity0.41 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
