YTO

LSD220H

Smooth Drum Roller

Operating Weight
44,093 lb
Max Speed
7.0 mph
Drum Width
84 in
Gross Power
190.5 hp
All smooth drum rollers
YTO LSD220H Smooth Drum Roller
1 / 5
Image 1 of 5
Image: okorder.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight44,093 lb
Max Speed7.0 mph
Operating Voltage24 V
Hydraulic System Fluid Capacity79.3 gal
Turning Radius276 in

Engine

Engine specifications
Engine Model6CT8.3
Gross Power190.5 hp

Dimensions

Dimensions specifications
Ground Clearance19 in
Height - Top of Cab119 in
Wheelbase11 in
Overall Length20 in
Overall Width91 in

Drum

Drum specifications
Drum Width84 in
Drum Diameter63 in
Vibration Frequency 135 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High83,179 lb
Vibration Frequency 229 vpm
Static Linear Load280 lb-ft
Centrifugal Force - Low60,699 lb
Nominal Amplitude - Low0 in
