YTO

LSS220

Smooth Drum Roller

Operating Weight
44,093 lb
Max Speed
6.6 mph
Drum Width
84 in
Gross Power
177.1 hp
All smooth drum rollers
YTO LSS220 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: ytocorp.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight44,093 lb
Max Speed6.6 mph
Fuel Capacity47.6 gal
Operating Voltage24 V
Hydraulic System Fluid Capacity52.9 gal

Engine

Engine specifications
Engine ModelD6114
Power Measured @2,000 rpm
Gross Power177.1 hp

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab119 in
Wheelbase10 in
Overall Length19 in
Overall Width90 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1-26

Drum

Drum specifications
Drum Width84 in
Drum Diameter63 in
Vibration Frequency 133 vpm
Nominal Amplitude - High0 in
Vibration Frequency 230 vpm
Static Linear Load215 lb-ft
Nominal Amplitude - Low0 in
