YTO

WY10B

Excavator

Operating Weight
23,810 lb
Max Digging Depth
163 in
Net Power
80.5 hp
All excavators
YTO WY10B Excavator
1 / 5
Image 1 of 5
Image: ua-usm.com.ua

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight23,810 lb
Hydraulic System Relief Valve Pressure4,061 psi

Engine

Engine specifications
Engine ModelLR4105ZG56
Power Measured @2,200 rpm
Net Power80.5 hp
AspirationTurbocharged

Dimensions

Dimensions specifications
Ground Clearance16 in
Height - Top of Cab109 in
Length of Track on Ground103 in
Tail Swing Radius77 in
Width to Outside of Tracks96 in
Removal Counterweight Clearance37 in

Undercarriage

Undercarriage specifications
Track Gauge76 in
Max Travel Speed7.8 mph
Shoe Size20 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth163 in
Max Loading Height158 in
Max Cutting Height222 in
Shipping Length of Unit267 in

Bucket

Bucket specifications
Reference Bucket Capacity0.60 yd³
