Zoomlion

YZ18

Smooth Drum Roller

Operating Weight
39,683 lb
Max Speed
6.3 mph
Drum Width
85 in
Gross Power
158.3 hp
All smooth drum rollers
Zoomlion YZ18 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: heavy-spec.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight39,683 lb
Max Speed6.3 mph
Operating Voltage24 V

Engine

Engine specifications
Engine ModelBF6L913
Power Measured @2,500 rpm
Gross Power158.3 hp

Dimensions

Dimensions specifications
Height - Top of Cab127 in
Overall Length20 in
Overall Width95 in
Drum Diameter - Front64 in

Tires & Wheels

Tires & Wheels specifications
Tires20.5-25

Drum

Drum specifications
Drum Width85 in
Drum Diameter63 in
Vibration Frequency 129 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High60,699 lb
Vibration Frequency 235 vpm
Static Linear Load27 lb-ft
Centrifugal Force - Low83,179 lb
Nominal Amplitude - Low0 in
