Zoomlion

YZ20E

Smooth Drum Roller

Operating Weight
44,093 lb
Max Speed
6.3 mph
Drum Width
85 in
Gross Power
189.1 hp
All smooth drum rollers
Zoomlion YZ20E Smooth Drum Roller
1 / 5
Image 1 of 5
Image: hfocusco.en.made-in-china.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight44,093 lb
Max Speed6.3 mph
Operating Voltage24 V

Engine

Engine specifications
Engine ModelBF6L913C
Power Measured @2,500 rpm
Gross Power189.1 hp

Dimensions

Dimensions specifications
Height - Top of Cab126 in
Overall Length20 in
Overall Width95 in
Drum Diameter - Front64 in

Tires & Wheels

Tires & Wheels specifications
Tires20.5-25

Drum

Drum specifications
Drum Width85 in
Drum Diameter63 in
Vibration Frequency 128 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High62,947 lb
Vibration Frequency 232 vpm
Static Linear Load27 lb-ft
Centrifugal Force - Low89,924 lb
Nominal Amplitude - Low0 in
