Zoomlion

YZ27

Smooth Drum Roller

Operating Weight
59,084 lb
Max Speed
6.3 mph
Drum Width
85 in
Gross Power
216.0 hp
All smooth drum rollers
Zoomlion YZ27 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: india-mproduct.global-ce.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight59,084 lb
Max Speed6.3 mph
Operating Voltage24 V

Engine

Engine specifications
Engine ModelBF6M1013C
Power Measured @2,300 rpm
Gross Power216.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab130 in
Overall Length21 in
Overall Width98 in
Drum Diameter - Front64 in

Tires & Wheels

Tires & Wheels specifications
Tires20.5-25

Drum

Drum specifications
Drum Width85 in
Drum Diameter63 in
Vibration Frequency 129 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High62,947 lb
Vibration Frequency 233 vpm
Static Linear Load37 lb-ft
Centrifugal Force - Low101,164 lb
Nominal Amplitude - Low0 in
