Zoomlion

YZC12

Smooth Drum Roller

Operating Weight
27,558 lb
Max Speed
8.0 mph
Drum Width
83 in
Gross Power
110.0 hp
All smooth drum rollers
Zoomlion YZC12 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: m.made-in-china.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight27,558 lb
Max Speed8.0 mph
Operating Voltage24 V

Engine

Engine specifications
Engine ModelF6L912
Power Measured @2,500 rpm
Gross Power110.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab121 in
Overall Length19 in
Overall Width94 in
Drum Diameter - Front50 in
Drum Diameter - Rear50 in

Tires & Wheels

Tires & Wheels specifications
Tires170

Drum

Drum specifications
Drum Width83 in
Drum Diameter49 in
Vibration Frequency 132 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High15,737 lb
Vibration Frequency 245 vpm
Static Linear Load14 lb-ft
Centrifugal Force - Low24,729 lb
Nominal Amplitude - Low0 in
