Zoomlion

YZD18

Smooth Drum Roller

Operating Weight
39,683 lb
Max Speed
4.1 mph
Drum Width
85 in
Gross Power
167.7 hp
All smooth drum rollers
Zoomlion YZD18 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: m.made-in-china.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight39,683 lb
Max Speed4.1 mph
Operating Voltage24 V

Engine

Engine specifications
Engine Model6BTA5.9
Power Measured @2,300 rpm
Gross Power167.7 hp

Dimensions

Dimensions specifications
Height - Top of Cab126 in
Overall Length20 in
Overall Width95 in
Drum Diameter - Front62 in

Tires & Wheels

Tires & Wheels specifications
Tires20.5-25

Drum

Drum specifications
Drum Width85 in
Drum Diameter62 in
Vibration Frequency 132 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High49,458 lb
Vibration Frequency 235 vpm
Static Linear Load20 lb-ft
Centrifugal Force - Low83,179 lb
Nominal Amplitude - Low0 in
