Airman
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 6,768 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 21.4 gal/min |
| Hydraulic System Relief Valve Pressure | 3,481 psi |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 30.0 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Length of Track on Ground | 66 in |
| Tail Swing Radius | 31 in |
| Width to Outside of Tracks | 61 in |
Undercarriage
| Max Travel Speed | 2.8 mph |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 111 in |
|---|---|
| Max Reach Along Ground | 193 in |
| Max Vertical Wall Digging Depth | 94 in |
| Max Loading Height | 128 in |
| Shipping Length of Unit | 176 in |
| Shipping Height of Unit | 100 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
