Allmand
John Deere
400
Backhoe Loader
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 4,045 lb |
|---|
Engine
| Net Power | 25.0 hp |
|---|
General Specifications
| Operating Weight lbs (kg) | 4,045 (1,834) Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 8.8 (2.7) Starting 2011 Model Year |
| Lift Capacity lbs (kgs) | 2,100 (952) Starting 2004 Model Year |
| Loading Height ft (m) | - Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | hydrostatic Starting 2004 Model Year |
| Backhoe Loading Height ft. (m) | 7.0 (2.1) Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | hydrostatic Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 3,400 (1,542) Starting 2004 Model Year |
| Digging Depth ft (m) | 8.10 (2.7) Starting 2008 Model Year |
| Loader SAE HP (kw) | 25 (18.5) Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 2,100 (952) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 3,400 (1,542) Starting 2009 Model Year |
| SAE Net hp (kW) | 25 (18.5) Starting 2007 Model Year |
| SAE HP (KW) | 25 (18.5) Starting 2010 Model Year |
| Weight lbs (kg) | 4,045 (1,834) Starting 2010 Model Year |
Backhoe
| Max Digging Depth | 106 in |
|---|---|
| Dig Depth | 97 in |
| Loading Height | 85 in |
Loader
| Lift Capacity | 2,100 lb |
|---|---|
| SAE - Net | 25.0 hp |
| Breakout Force | — |
