Allmand
John Deere
302A
Backhoe Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 4,690 lb |
|---|
Engine
| Net Power | 33.3 hp |
|---|
Transmission
| Max Speed | — |
|---|
General Specifications
| Operating Weight lbs (kg) | 4,690 (2,127) — Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 9.9 (3.0) — Starting 2011 Model Year |
| Lift Capacity lbs (kgs) | 2,100 (952) — Starting 2004 Model Year |
| Loading Height ft (m) | 7.8 (2.3) — Starting 2008 Model Year |
| 4th Gear Fwd mph (kmh) | hydrostatic — Starting 2004 Model Year |
| Backhoe Loading Height ft. (m) | 7.7 (2.3) — Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | hydrostatic — Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 3,400 (1,542) — Starting 2004 Model Year |
| Digging Depth ft (m) | 9.11 (3.0) — Starting 2008 Model Year |
| Loader SAE HP (kw) | 33.3 (24.6) — Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 2,100 (952) — Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 3,400 (1,542) — Starting 2009 Model Year |
| SAE Net hp (kW) | 33.3 (24.6) — Starting 2007 Model Year |
| SAE HP (KW) | 33.3 (24.6) — Starting 2010 Model Year |
| Weight lbs (kg) | 4,690 (2,127) — Starting 2010 Model Year |
Backhoe
| Dig Depth | 109 in |
|---|---|
| Load Height | 94 in |
Loader
| Bucket Breakout Force | 3,400 lb |
|---|---|
| SAE - Net | 33.3 hp |
