Ammann

ASC110PD

Padfoot Compactor

Operating Weight
26,290 lb
Max Speed
6.6 mph
Drum Width
87 in
All padfoot compactors
Ammann ASC110PD Padfoot Compactor
1 / 5
Image 1 of 5
Image: ammannvietnam.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight26,290 lb
Max Speed6.6 mph
Fuel Capacity108.4 gal

Engine

Engine specifications
Engine ModelQSB4.5-C160
Net Power158.0 hp

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab120 in
Wheelbase9 in
Width Over Tires96 in
Overall Length w/o Blade224 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1-26

Drum

Drum specifications
Drum Width87 in
Vibration Frequency 132 vpm
Centrifugal Force - High46,311 lb
Drum Diameter57 in
Nominal Amplitude - High0 in
Pad Height4 in
Number of Pads140
Centrifugal Force - Low62,272 lb
Nominal Amplitude - Low0 in
Vibratory Frequency 235 vpm
Pad Surface Area19 in³
