Ammann
Dynapac
CA610PD
Padfoot Compactor
29 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 34,227 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 108.4 gal |
Engine
| Engine Model | QSB4.5-C160 |
|---|---|
| Net Power | 158.0 hp |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 9 in |
| Width Over Tires | 100 in |
| Overall Length w/o Blade | 224 in |
Tires & Wheels
| Tires | 23.1-26 |
|---|
Drum
| Drum Width | 87 in |
|---|---|
| Vibration Frequency 1 | 29 vpm |
| Centrifugal Force - High | 53,280 lb |
| Drum Diameter | 57 in |
| Nominal Amplitude - High | 0 in |
| Pad Height | 4 in |
| Number of Pads | 140 |
| Centrifugal Force - Low | 73,063 lb |
| Nominal Amplitude - Low | 0 in |
| Vibratory Frequency 2 | 35 vpm |
| Pad Surface Area | 19 in³ |
