Ammann

ASC200HD

Smooth Drum Roller

Operating Weight
48,292 lb
Max Speed
6.6 mph
Drum Width
88 in
All smooth drum rollers
Ammann ASC200HD Smooth Drum Roller
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight48,292 lb
Max Speed6.6 mph
Fuel Capacity107.0 gal

Engine

Engine specifications
Engine ModelQSB6.7-C220
Net Power208.0 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab130 in
Wheelbase10 in
Overall Length21 in
Overall Width100 in
Drum Diameter - Front67 in

Tires & Wheels

Tires & Wheels specifications
Tires23.5-25

Drum

Drum specifications
Drum Width88 in
Drum Diameter67 in
Vibration Frequency 128 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High67,443 lb
Vibration Frequency 234 vpm
Static Linear Load29 lb-ft
Centrifugal Force - Low89,924 lb
Nominal Amplitude - Low0 in
