Ammann

ASC200HDPD

Padfoot Compactor

Operating Weight
48,447 lb
Max Speed
6.6 mph
Drum Width
88 in
All padfoot compactors
Ammann ASC200HDPD Padfoot Compactor
1 / 5
Image 1 of 5
Image: ammann.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight48,447 lb
Max Speed6.6 mph
Fuel Capacity107.0 gal

Engine

Engine specifications
Engine ModelQSB6.7-C220
Net Power208.0 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab130 in
Wheelbase10 in
Width Over Tires100 in
Overall Length w/o Blade248 in

Tires & Wheels

Tires & Wheels specifications
Tires23.5-25

Drum

Drum specifications
Drum Width88 in
Vibration Frequency 128 vpm
Centrifugal Force - High67,443 lb
Drum Diameter63 in
Nominal Amplitude - High0 in
Pad Height5 in
Number of Pads150
Centrifugal Force - Low89,924 lb
Nominal Amplitude - Low0 in
Vibratory Frequency 234 vpm
Pad Surface Area22 in³
