JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 43,431 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 124.2 gal/min |
| Hydraulic System Relief Valve Pressure | 4,772 psi |
Engine
| Engine Model | C 6D34-TLE 2A |
|---|---|
| Net Power | 147.6 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 111 in |
Undercarriage
| Shoe Size | 24 in |
|---|
Boom/Stick Excavator Option 1
| Max Digging Depth | 224 in |
|---|---|
| Max Reach Along Ground | 348 in |
| Max Loading Height | 252 in |
| Max Cutting Height | 192 in |
