Bobcat
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 6,145 lb |
|---|---|
| Fuel Capacity | 14.1 gal |
| Hydraulic Pump Flow Capacity | 17.5 gal/min |
Engine
| Engine Model | D1703-M-E2B |
|---|---|
| Displacement | 98 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 27.7 hp |
Dimensions
| Height - Top of Cab | 94 in |
|---|---|
| Length of Track on Ground | 55 in |
| Tail Swing Radius | 47 in |
| Width to Outside of Tracks | 55 in |
| Removal Counterweight Clearance | 22 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 43 in |
| Max Travel Speed | 1.9 mph |
| Shoe Size | 13 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 1,207 in |
|---|---|
| Max Reach Along Ground | 2,000 in |
| Max Vertical Wall Digging Depth | 72 in |
| Max Loading Height | 110 in |
| Shipping Length of Unit | 166 in |
| Max Cutting Height | 161 in |
| Shipping Height of Unit | 94 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
