Bobcat
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 7,758 lb |
|---|---|
| Fuel Capacity | 15.3 gal |
| Hydraulic Pump Flow Capacity | 24.1 gal/min |
Engine
| Engine Model | V-2203-M-DI-E2B |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 40.1 hp |
Dimensions
| Height - Top of Cab | 94 in |
|---|---|
| Length of Track on Ground | 62 in |
| Tail Swing Radius | 55 in |
| Width to Outside of Tracks | 61 in |
| Removal Counterweight Clearance | 20 in |
| Digging Depth | 154 in |
| Digging Reach | 154 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 49 in |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 13 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 155 in |
|---|---|
| Max Reach Along Ground | 222 in |
| Max Vertical Wall Digging Depth | 101 in |
| Max Loading Height | 134 in |
| Shipping Length of Unit | 198 in |
| Max Cutting Height | 190 in |
| Shipping Height of Unit | 94 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
