Bobcat
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 4,306 lb |
|---|---|
| Fuel Capacity | 5.0 gal |
Engine
| Power Measured @ | 2,500 rpm |
|---|---|
| Net Power | 13.9 hp |
| Fuel | Diesel |
| Emissions | Tier 4 |
Hydraulic System
| Pump Flow Capacity | 7.9 gal/min |
|---|---|
| Operating pressure | 2,610 psi |
Dimensions
| Height - Top of Cab | 91 in |
|---|---|
| Height | 90 in |
| Length | 145 in |
| Width | 39 in |
Undercarriage
| Max Travel Speed | 2.5 mph |
|---|---|
| Min Travel Speed | 1.5 mph |
Boom/Stick Excavator Option 1
| Max Digging Depth | 102 in |
|---|---|
| Max Reach Along Ground | 168 in |
| Max.Dumping Height | 106 in |
| Boom Swing - Left | 80 ° |
| Boom Swing - Right | 60 ° |
| Arm Digging Force | 2,086 lb |
| Bucket Digging Force | 4,684 lb |
General Specifications
| Operating Weight lbs (kg) | 4,306 (1,953) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 8.42 (2.57) — Starting 2025 Model Year |
| Engine hp (kW) | 15 (11.2) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 13.99 (4.26) — Starting 2025 Model Year |
| Bucket Breakout Force lbf (N) | 4,684 (20,835) — Starting 2025 Model Year |
Lift System
| Max Lift Capacity | 1,023 lb |
|---|---|
| Lift Radius | 118 in |
