Bobcat
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 7,699 lb |
|---|---|
| Operating Weight (35 ) | 7,909 lb |
| Fuel Capacity | 13.7 gal |
Engine
| Power Measured @ | 2,550 rpm |
|---|---|
| Net Power | 24.8 hp |
| Fuel | Diesel |
| Emissions | Tier 4 |
| Net Power (35 ) | 33.5 hp |
| Power Measured @ (35 ) | 2,400 rpm |
Hydraulic System
| Pump Flow Capacity | 16.9 gal/min |
|---|---|
| Operating pressure | 2,987 psi |
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Height | 96 in |
| Length | 190 in |
| Width | 69 in |
Undercarriage
| Max Travel Speed | 2.9 mph |
|---|---|
| Min Travel Speed | 1.6 mph |
Boom/Stick Excavator Option 1
| Max Digging Depth | 122 in |
|---|---|
| Max Reach Along Ground | 206 in |
| Max.Dumping Height | 132 in |
| Boom Swing - Left | 75 ° |
| Boom Swing - Right | 55 ° |
| Arm Digging Force | 4,859 lb |
| Bucket Digging Force | 6,968 lb |
General Specifications
| Operating Weight lbs (kg) | 7,659 (3,474) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 10.1 (3.08) Starting 2025 Model Year |
| Engine hp (kW) | 24.8 (18.5) Starting 2025 Model Year |
| Digging Reach ft. (m) | 17.03 (5.19) Starting 2025 Model Year |
| Bucket Breakout Force lbf (N) | 7,284 (32,402) Starting 2025 Model Year |
Lift System
| Max Lift Capacity | 3,232 lb |
|---|---|
| Lift Radius | 118 in |
