Bobcat
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 9,246 lb |
|---|---|
| Fuel Capacity | 21.1 gal |
Engine
| Power Measured @ | 2,200 rpm |
|---|---|
| Net Power | 42.7 hp |
| Fuel | Diesel |
| Emissions | Tier 4 |
Hydraulic System
| Pump Flow Capacity | 20.0 gal/min |
|---|---|
| Operating pressure | 3,045 psi |
Dimensions
| Height - Top of Cab | 100 in |
|---|---|
| Height | 99 in |
| Length | 200 in |
| Width | 69 in |
Undercarriage
| Max Travel Speed | 2.9 mph |
|---|---|
| Min Travel Speed | 1.6 mph |
Boom/Stick Excavator Option 1
| Max Digging Depth | 126 in |
|---|---|
| Max Reach Along Ground | 207 in |
| Max.Dumping Height | 146 in |
| Boom Swing - Left | 75 ° |
| Boom Swing - Right | 50 ° |
| Arm Digging Force | 5,762 lb |
| Bucket Digging Force | 9,183 lb |
Lift System
| Max Lift Capacity | 4,603 lb |
|---|---|
| Lift Radius | 118 in |
