BOMAG
Caterpillar
826H
Landfill Compactor
46 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 120,000 lb |
|---|---|
| Fuel Capacity | 264.2 gal |
| Hydraulic System Fluid Capacity | 155.9 gal |
| Engine Oil Capacity | 11.9 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | TCD 2015V08 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 598.0 hp |
| Number of Cylinders | 8 |
Dimensions
| Ground Clearance | 31 in |
|---|---|
| Height - Top of Cab | 191 in |
| Wheelbase | 162 in |
| Width Over Wheels | 178 in |
Transmission
| Max Speed | 7.5 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
| Transmission Type | hydrostatic |
Blades
| Blade Width | 205 in |
|---|---|
| Blade Height | 88 in |
Wheels
| Front Wheels Drum Diameter | 87 in |
|---|---|
| Front Wheels Drum Width | 55 in |
| Rear Wheels Drum Diameter | 87 in |
| Rear Wheels Drum Width | 55 in |
