Broderson
Shuttlelift
3330F
Carrydeck Crane
31 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 16,260 lb |
|---|---|
| Operating Voltage | 12 V |
| Tire Size | 10.00x15 |
| Fuel Capacity | 20.0 gal |
| Hydraulic System Fluid Capacity | 25.0 gal |
Engine
| Engine Model | GM 3.0 EFI |
|---|---|
| Displacement | 181 in³ |
| Gross Power | 69.0 hp |
| Max Torque | 163 lb-ft |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 7 in |
| Transport Width | 78 in |
| Transport Height | 88 in |
| Transport Length | 178 in |
| Width w/ Outriggers Extended | 115 in |
| Upper Structure Tail Swing Radius | 57 in |
| Carrier/Base Length | 155 in |
Transmission
| Max Speed - Forward | 20.0 mph |
|---|---|
| Max Speed - Reverse | 20.0 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Boom
| Max Lift Capacity | 18,000 lb |
|---|---|
| Max Elevating Angle | 70 ° |
| Max Height @ Max Raise Angle - no jib | 381 in |
| Min Height @ Max Raise Angle | 219 in |
| Number of Sections | 3 |
| Swing Speed | 2 rpm |
| Max Operating Radius | 408 in |
| Min Operating Radius | 60 in |
