CaseCase
570N EP
Skip Loader
36 specifications
1 / 5
Image 1 of 5
Specifications
13 data points
Operating Specifications
| Operating Weight | 10,347 lb |
|---|
General Specifications
| Operating Weight lbs (kg) | 10,347 (4,693) — Starting 2007 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 6,503 (2,949) — Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 25.0 (40.2) — Starting 2007 Model Year |
| Breakout Force lbs (kgs) | 9,271(4,205) — Starting 2007 Model Year |
| Digging Depth ft (m) | NA — Starting 2004 Model Year |
| Loading Height ft (m) | 11.2 (3.4) — Starting 2004 Model Year |
| SAE Net hp (kW) | 73 (54) — Starting 2004 Model Year |
Backhoe
| Loading Height | 134 in |
|---|
Loader
| Lift Capacity | 6,503 lb |
|---|---|
| SAE - Net | 73.0 hp |
| Breakout Force | — |
Travel Speed
| 4th Gear Fwd | 25.0 mph |
|---|
