Case
John Deere
210C
Skip Loader
49 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 11,136 lb |
|---|---|
| Fuel Capacity | 30.2 gal |
| Hydraulic System Fluid Capacity | 28.5 gal |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.2 gal |
| Front Axle Fluid Capacity | 0.2 gal |
| Rear Axle Fluid Capacity | 3.6 gal |
Engine
| Engine Model | FPT F5HFL463D |
|---|---|
| Displacement | 208 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 74.0 hp |
| Net Power | 72.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Bore | 4 in |
| Stroke | 4 in |
| Engine Type | Diesel 4-stroke Turbocharged |
| Emissions Certification | Tier 4 Final |
| Net Max Torque | 228 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 28.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 131 in |
|---|---|
| Wheelbase | 84 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 24.0 mph |
|---|---|
| Max Speed - Reverse | 24.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Syncroshuttle |
Brakes & Steering
| Service brake | Wet Multi Disc |
|---|
Tires & Wheels
| Rear Tires Size | 19.5 L x 24.0 10-ply |
|---|
Loader
| Reach at Max Dump Height | 2 in |
|---|
Electrical System
| Alternator | 120 |
|---|---|
| Battery | 850 cold-cranking |
