Case
Ingersoll Rand
BL370
Backhoe Loader
30 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Fuel Capacity | 28.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 17.5 gal |
| Tire Size Front - 2wd / 4wd | 11Lx16 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Max Weight | 14,500 lb |
Engine
| Engine Model | 267D |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 71.0 hp |
| Net Power | 64.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Engine Make | J.I. Case |
| Stroke | 5 in |
| Bore | 4 in |
| Net Max Torque | 205 lb-ft |
Hydraulic System
| Pump Flow Capacity | 25.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,150 psi |
| Pump Type | Open center |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 80 in |
| Rear Tread Range | 67 in |
| Front Wheel Tread Width | 71 in |
Transmission
| Max Speed | 18.1 mph |
|---|---|
| Max Speed - Reverse | 23.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Power shuttle |
Tires & Wheels
| Rear Tires Size | 16.9x24 |
|---|
Backhoe
| Dig Depth | 192 in |
|---|---|
| Reach From Swivel | 229 in |
| Load Height | 137 in |
Loader
| Bucket Breakout Force | 1,024,679 lb |
|---|---|
| Bucket Width | 85 in |
| Reach at Max Dump Height | 67 in |
