Case
JCB
210S
Backhoe Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight 2wd | 16,960 lb |
|---|---|
| Fuel Capacity | 30.0 gal |
| Hydraulic System Fluid Capacity | 13.8 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Oil System Fluid Capacity | 2.6 gal |
| Transmission Fluid Capacity | 3.0 gal |
| Rear Axle Fluid Capacity | 3.4 gal |
Engine
| Engine Model | 336 |
|---|---|
| Displacement | 336 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 80.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,500 rpm |
| Net Max Torque | 221 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 85 in |
| Transport Width | 91 in |
| Transport Length | 268 in |
| Height to Top of Suspended Cab | 110 in |
Transmission
| Max Speed | 19.4 mph |
|---|---|
| Max Speed - Reverse | 19.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | syncromesh |
Tires & Wheels
| Rear Tires Size | 16.9x24 |
|---|
Backhoe
| Dig Depth | 202 in |
|---|---|
| Reach From Swivel | 240 in |
| Dig Depth - Extended | 251 in |
| Load Height - Extended | 151 in |
| Reach From Swivel - Extended | 288 in |
| Reach at Load Height - Extended | 158 in |
Loader
| Bucket Capacity | 1.60 yd³ |
|---|---|
| Clearance at Max Dump Height | 115 in |
| Bucket Width | 96 in |
| Dig Depth | 4 in |
