JCB
John Deere
302A
Backhoe Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 10,196 lb |
|---|
General Specifications
| Operating Weight lbs (kg) | 10,196 (4,626) — Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 4,850 (2,200) — Starting 2004 Model Year |
| Loading Height ft (m) | 8.5 (2.59) — Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 19.5 (31.5) — Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 8,706 (3,950) — Starting 2004 Model Year |
| Digging Depth ft (m) | 9.8 (3.01) — Starting 2004 Model Year |
| SAE Net hp (kW) | 60 (45) — Starting 2004 Model Year |
Backhoe
| Max Digging Depth | 118 in |
|---|---|
| Loading Height | 102 in |
Loader
| Lift Capacity | 4,850 lb |
|---|---|
| SAE - Net | 60.0 hp |
| Breakout Force | — |
Travel Speed
| 4th Gear Fwd | 19.5 mph |
|---|
