Case

845 DHP

Motor Grader

Max Power
160.0 hp
Net Power Gears 7-8
160.0 hp
All motor graders
Case 845 DHP Motor Grader
1 / 5
Image 1 of 5
Image: casece.com

Specifications

51 data points

Operating Specifications

Operating Specifications specifications
Std Operation Weight - Total29,777 lb
Tire Size14.0 x 24 12PR TL G2 Firestone
Fuel Capacity90.0 gal
Std Operation Weight - Front Axle8,155 lb
Std Operation Weight - Rear Axle21,621 lb
Hydraulic System Fluid Capacity47.5 gal
Tandem Case Fluid Capacity (each)7.6 gal
Operating Voltage24 V
Cooling System Fluid Capacity10.5 gal
Alternator Supplied Amperage80 A
Transmission Fluid Capacity6.6 gal
Circle Gearbox Fluid Capacity0.8 gal
Rear Diff/Final Drive Fluid Capacity3.2 gal
Oil System Fluid Capacity4.3 gal

Engine

Engine specifications
Engine ModelQSB 6.7 Tier III certified electronic controlled
Displacement411 in³
Power Measured @2,200 rpm
Number of Cylinders6
Aspirationturbocharged and air to air aftercooled
Torque Measured @1,500 rpm
Max Power160.0 hp
Net Power Gears 7-8160.0 hp
Net Torque Gears 7-8550 lb-ft

Hydraulic System

Hydraulic System specifications
Pump Flow50.5 gal/min
Pump TypeClosed center load sensing gear pump.

Dimensions

Dimensions specifications
Wheelbase246 in
Overall Length336 in
Width Over Tires100 in
Height to Top of Isomount Cab132 in
Blade Base102 in
Tandem Axle Wheelbase62 in
Front Ground Clearance25 in
Rear Ground Clearance16 in

Transmission

Transmission specifications
Max Speed - Forward26.6 mph
Max Speed - Reverse17.7 mph
Number of Gears - Forward8
Number of Gears - Reverse4
Transmission TypeDirect drive countershaft powershift w/ electronic shift control and inching pedal

Moldboard

Moldboard specifications
Moldboard Height22 in
Moldboard Width144 in
Moldboard Thickness1 in
Side Shift Left21 in
Side Shift Right27 in
Max Depth of Cut28 in

Circle

Circle specifications
Max Lift Above Ground18 in
Diameter69 in
Rotation360 °

Front Axle

Front Axle specifications
Wheel Lean18 °
Oscillation - Total19 °

Steering System

Steering System specifications
Turning Radius285 in
Articulation Angle25 °
