John Deere
Champion
730A
Motor Grader
53 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Max Operation Weight - Total | 36,780 lb |
|---|---|
| Max Operation Weight - Front Axle | 10,650 lb |
| Max Operation Weight - Rear Axle | 26,130 lb |
| Std Operation Weight - Total | 32,500 lb |
| Tire Size | 14.00-24 |
| Fuel Capacity | 89.9 gal |
| Std Operation Weight - Front Axle | 9,400 lb |
| Std Operation Weight - Rear Axle | 23,100 lb |
| Hydraulic System Fluid Capacity | 23.0 gal |
| Tandem Case Fluid Capacity (each) | 5.0 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 10.1 gal |
| Alternator Supplied Amperage | 50 A |
| Circle Gearbox Fluid Capacity | 1.1 gal |
| Oil System Fluid Capacity | 6.5 gal |
Engine
| Engine Model | 6076A |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,100 rpm |
| Net Power Gear 4-6 | 185.0 hp |
| Net Power Gear 1-3 | 155.0 hp |
Hydraulic System
| Pump Flow | 52.4 gal/min |
|---|---|
| Pump Type | Closed Center Variable Displacement |
Dimensions
| Wheelbase | 235 in |
|---|---|
| Overall Length | 336 in |
| Height to Top of Isomount Cab | 122 in |
| Blade Base | 106 in |
| Tandem Axle Wheelbase | 61 in |
| Front Ground Clearance | 23 in |
Transmission
| Max Speed - Forward | 25.3 mph |
|---|---|
| Max Speed - Reverse | 8.6 mph |
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 4 |
| Transmission Type | Power Shift |
Moldboard
| Moldboard Height | 24 in |
|---|---|
| Moldboard Thickness | 1 in |
| Side Shift Left | 27 in |
| Side Shift Right | 27 in |
| Moldboard Length | 145 in |
Circle
| Max Lift Above Ground | 19 in |
|---|---|
| Max Reach Outside Tires - Left | 85 in |
| Max Reach Outside Tires - Right | 83 in |
| Diameter | 59 in |
| Blade Tip Angle - Front | 49 ° |
| Rotation | 360 ° |
| Blade Tip Angle - Rear | 5 ° |
| Shift Left | 31 in |
| Shift Right | 29 in |
Front Axle
| Wheel Lean | 20 ° |
|---|---|
| Oscillation - Total | 32 ° |
| Ground Clearance | 23 in |
Steering System
| Turning Radius | 271 in |
|---|---|
| Articulation Angle | 25 ° |
