Case
9030B Narrow
- Operating Weight
- 44,000 lb
- Max Digging Depth
- 264 in
- Max Digging Depth
- 241 in
- Net Power
- 131.0 hp
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 44,000 lb |
|---|---|
| Fuel Capacity | 82.0 gal |
| Hydraulic Pump Flow Capacity | 51.3 gal/min |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Hydraulic System Relief Valve Pressure | 4,554 psi |
| Engine Oil Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 6.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | 6T-590 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 131.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 425 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 110 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 41,140 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 385 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 240 in |
| Max Cutting Height | 373 in |
| Shipping Length of Unit | 372 in |
| Shipping Height of Unit | 117 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 241 in |
|---|---|
| Max Vertical Wall Digging Depth | 216 in |
| Max Cutting Height | 365 in |
| Max Loading Height | 216 in |
| Max Reach Along Ground | 365 in |
| Shipping Length of Unit | 377 in |
| Shipping Height of Unit | 121 in |
