Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 62,170 lb |
|---|---|
| Fuel Capacity | 82.0 gal |
| Hydraulic Pump Flow Capacity | 56.1 gal/min |
| Hydraulic System Fluid Capacity | 57.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 65 A |
Engine
| Engine Model | 6T-830 |
|---|---|
| Displacement | 505 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 178.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 558 lb-ft |
| Engine Make | Case |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 191 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 134 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 48,109 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 306 in |
|---|---|
| Max Reach Along Ground | 437 in |
| Max Loading Height | 283 in |
| Max Vertical Wall Digging Depth | 276 in |
| Max Cutting Height | 403 in |
| Shipping Length of Unit | 395 in |
| Shipping Height of Unit | 125 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 283 in |
|---|---|
| Max Vertical Wall Digging Depth | 253 in |
| Max Cutting Height | 401 in |
| Max Loading Height | 278 in |
| Max Reach Along Ground | 418 in |
| Shipping Length of Unit | 40 in |
| Shipping Height of Unit | 132 in |
