Case
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Operating Weight | 33,290 lb |
|---|---|
| Arm Breakout Force | 14,837 lb |
| Arm size | 98,425 in |
Engine
| Engine Model | Isuzu 4 JJ 1X |
|---|---|
| Displacement | 952 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 100.0 hp |
| Max Torque | 265 lb-ft |
| Engine Make | Isuzu |
| Stroke | 4 in |
| Bore | 4 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Interim Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Weights
| Counterweight | 8,157 lb |
|---|
Hydraulic System
| Main pump - Maximum flow | 68.2 gal |
|---|---|
| System relief pressure | 4,970 psi |
Dimensions
| Tail Swing Radius | 61 in |
|---|---|
| Overall Height | 110 in |
| Track Shoe Width | 24 in |
| Cab height | 110 in |
| Center to center - idler to sprocket | 120 in |
| Ground pressure | 363 psi |
| Boom length | 186 in |
| Minimum ground clearance | 17 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 24 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 52.9 gal |
|---|---|
| Hydraulic system | 41.8 gal |
| Hydraulic Tank | 19.9 gal |
| Cooling system | 4.1 gal |
| Engine oil w/ filter change | 4.5 gal |
| Swing drive | 0.8 gal |
| Final Drive | 0.6 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 217 in |
|---|---|
| Max Reach Along Ground | 320 in |
| Max Vertical Wall Digging Depth | 193 in |
| Minimum swing radius | 77 in |
| Max.Dumping Height | 274 in |
| Max Digging Reach on Ground | 322 in |
| Bucket rotation | 178 ° |
| Mximum dig radius | 326 in |
| Dig radius at ground line | 321 in |
| Dump height | 273 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 209 in |
|---|---|
| Minimum swing radius | 92 in |
| Bucket rotation | 178 ° |
| Dig radius at ground line | 339 in |
| Dump height | 287 in |
| Maximum dig radius | 344 in |
| Maximum reach height | 3,819 in |
Boom/Stick Excavator Option 3
| Overall height | 110 in |
|---|
Performance
| Lift over end Max. reach | 2,800 lb |
|---|---|
| Lift over side Max. reach | 2,800 lb |
| Lift over end 10' radius | 19,251 lb |
| Lift over side 10' radius | 13,600 lb |
