Case
Komatsu
PC100
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Operating Weight | 38,360 lb |
|---|---|
| Arm Breakout Force | 14,837 lb |
| Arm size | 98 in |
Engine
| Engine Model | Isuzu 4 JJ 1X |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 112.0 hp |
| Max Torque | 257 lb-ft |
| Engine Make | Isuzu |
| Bore | 4 in |
| Stroke | 4 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
| Horsepower per SAE J1349 Net | 112.0 hp |
Hydraulic System
| Main pump - Maximum flow | 37.6 gal |
|---|---|
| System relief pressure | 4,970 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Tail Swing Radius | 98 in |
| Overall Height | 118 in |
| Track Shoe Width | 24 in |
| Cab height | 117 in |
| Track length | 157 in |
| Center to center - idler to sprocket | 126 in |
| Ground pressure | 6 psi |
| Boom length | 1 in |
Transmission
| Max Speed | 3.4 mph |
|---|
Undercarriage
| Track Shoe Width | 24 in |
|---|
Brakes & Steering
| Service brake | Mechanical disc |
|---|---|
| Brakes Type | Dual stage relief or counter balance design |
| Travel control | SAHR disc - each motor |
Fluid Capacities
| Fuel Tank | 79.3 gal |
|---|---|
| Hydraulic system | 43.6 gal |
| Cooling system | 4.3 gal |
| Hydraulic Tank | 23.8 gal |
| Engine oil w/ filter change | 4.5 gal |
| Swing drive | 1.4 gal |
| Final Drive | 1.6 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 230 in |
|---|---|
| Max Reach Along Ground | 365 in |
| Max Vertical Wall Digging Depth | 200 in |
| Minimum swing radius | 118 in |
| Max.Dumping Height | 252 in |
| Max Digging Reach on Ground | 313 in |
| Mximum dig radius | 370 in |
| Dig radius at ground line | 349 in |
| Dump height | 260 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 256 in |
|---|---|
| Max Vertical Wall Digging Depth | 206 in |
| Minimum swing radius | 120 in |
| Dig radius at ground line | 363 in |
| Dump height | 263 in |
| Maximum dig radius | 369 in |
| Maximum reach height | 366 in |
Boom/Stick Excavator Option 3
| Overall height | 118 in |
|---|
Performance
| Lift over end Max. reach | 3,849 lb |
|---|---|
| Lift over side Max. reach | 14,573 lb |
| Lift over end 10' radius | 17,201 lb |
| Lift over side 10' radius | 16,250 lb |
