JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 47,400 lb |
|---|---|
| Fuel Capacity | 108.3 gal |
| Hydraulic Pump Flow Capacity | 55.8 gal/min |
| Hydraulic System Fluid Capacity | 63.0 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 6.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 4HK1X Tier III certified |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 157.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 463 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 108 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 42,534 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 269 in |
| Max Vertical Wall Digging Depth | 235 in |
| Max Cutting Height | 380 in |
| Shipping Length of Unit | 371 in |
| Shipping Height of Unit | 118 in |
Bucket
| Maximum Bucket Capacity | 1.60 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Vertical Wall Digging Depth | 217 in |
| Max Cutting Height | 370 in |
| Max Loading Height | 259 in |
| Max Reach Along Ground | 365 in |
| Shipping Length of Unit | 373 in |
| Shipping Height of Unit | 126 in |
